Arizona Metals Corp’s Kay Mine Drilling Intersects 68.4 m at 6.7 g/t AuEq; 84.4 m at 5.3 g/t AuEq; and 72.5 m at 2.5% CuEq

TORONTO / Mar 23, 2022 / Business Wire / Arizona Metals Corp. (TSX.V:AMC, OTCQX:AZMCF) (the “Company” or “Arizona Metals”) is pleased to announce the results of six recently completed drill holes at its Kay Mine project in Yavapai, County Arizona. An additional 20 holes are pending, with three drill rigs turning 24 hours per day.

Marc Pais, CEO, commented “Drilling at the Kay Mine Project continues to intersect very large widths and high grades of massive sulphide mineralization. The holes released today demonstrate excellent continuity of mineralization in all directions, while also showing that mineralization is substantially thicker than suggested by our original modelling. Drilling has extended mineralization well into both the hanging-wall and foot-wall envelopes, which gives the potential to define a significant tonnage of mineralization.

Hole 51B showed the deepest mineralization assayed to date, at a vertical depth of 900 meters. Drilling is currently underway to test for depth extensions to at least 1,100 meters, while also testing for lateral extensions of the thick hinge zone. The twenty holes pending all encountered semi-massive or massive sulphide mineralization, and those intersections are guiding the drilling currently underway.

We have drilled approximately 45,000 meters at Kay to date, with each hole solidifying our opinion that this is one of the very few large precious-metals rich VMS deposits not yet mined, and more importantly, is potentially part of a much larger mineralized system that has yet to be explored. To that end, we recently completed a property-wide ground-loop electromagnetic survey, which will serve to refine and improve the resolution of the Central and Western targets, located approximately 300 meters and 1,000 meters west of Kay, respectively. Drill pad and road permitting is currently underway for these targets, with a detailed update expected in the next few weeks.”

Drilling Highlights

• Hole KM-21-58 intersected 68.4 m at a grade of 6.7 g/t AuEq, including higher-grade intervals of 7.3 m grading 10.1 g/t AuEq and 10.5 m grading 21.1 g/t AuEq, from a depth of 614 m. This hole is in the central portion of the deposit, and demonstrates excellent continuity of mineralization between holes 26, 28, 25A, and 40.
• Hole KM-21-58A intersected 72.5 m at a grade of 2.5% CuEq, including higher grade intervals of 7.6 m grading 3.0% CuEq, 11.0 m grading 4.3% CuEq, and 8.3 m grading 4.2% CuEq, from a depth of 569 m. This hole is in the central portion of the deposit, and demonstrates continuity and extension of mineralization between holes 26, 28, 25A, and 40.
• Hole KM-21-58B intersected 84.4 m at a grade of 5.3 g/t AuEq, including higher grade intervals of 11.3 m grading 10.3 g/t AuEq, and 17.4 m grading 11.2 g/t AuEq, from a depth of 597 m. This hole is in the central portion of the deposit, and demonstrates continuity of mineralization between holes 26, 28, 25A, and 40.
• Hole KM-21-51B intersected 9.8 m at a grade of 2.8% CuEq, including a higher grade interval of 0.9 m grading 8.0% CuEq, from a depth of 861m. At 10.6 m farther down-hole, this hole also intersected 9.8 m grading 1.4% Cu, including 1.1 meters grading 6.1% CuEq. This is the deepest hole assayed to date, extending mineralization about 35 m north and 12 m downdip from hole 42C.
• Hole KM21-57 intersected 7.8 m grading 3.9 g/t AuEq, including a higher grade interval of 0.9 m at a grade of 12.7 g/t AuEq, from a depth of 820 m. Thirty-five meters farther downhole, this hole intersected 15.5 m at a grade of 3.3% CuEq including a higher grade interval of 3.5 m grading 7.5% CuEq. This hole shows excellent continuity of high-grade mineralization between holes 27A and 42A.

Kay Mine Phase 2 Drill Program Update

With the assayed holes released today, the Company has completed a total of 45,000 meters at the Kay Mine since inception of drilling. The Company is fully-funded to complete the remaining 30,000 meters planned for the Phase 2 program, as well as an additional 76,000 meters in the upcoming Phase 3 program.

Table 1. Results of Phase 2 Drill Program at Kay Mine, Yavapai County, Arizona announced in this news release.

The true width of mineralization is estimated to be 50% to 99% of reported core width, with an average of 80%. (2) Assumptions used in USD for the copper and gold Metal Equivalent calculations were metal prices of $4.63/lb Copper, $1937/oz Gold, $25/oz Silver, $1.78/lb Zinc, and $1.02/lb Pb. Assumed metal recoveries (rec.), based on a preliminary review of historic data by SRK and ProcessIQ¹, were 90% for each of copper, zinc, and lead, and 60% for each of gold and silver. The following equation was used to calculate copper equivalence: CuEq = Copper (%) (90% rec.) + (Gold (g/t) x 0.61)(60% rec.) + (Silver (g/t) x 0.0079)(60% rec.) + (Zinc (%) x 0.3844)(90% rec.) +(Lead (%) x 0.2203)(90% rec.). The following equation was used to calculate gold equivalence: AuEq = Gold (g/t)(60% rec.) + (Copper (%) x 1.638)(90% rec.) + (Silver (g/t) x 0.01291)(60% rec.) + (Zinc (%) x 0.6299)(90% rec.) +(Lead (%) x 0.3609)(90% rec.). Analyzed Metal Equivalent calculations are reported for illustrative purposes only. The metal chosen for reporting on an equivalent basis is the one that contributes the most dollar value after accounting for assumed recoveries.

Table 2. Full results of Phase 2 Drill Program at Kay Mine, Yavapai County, Arizona.

The true width of mineralization is estimated to be 50% to 99% of reported core width, with an average of 80%. (2) Assumptions used in USD for the copper and gold Metal Equivalent calculations were metal prices of $4.63/lb Copper, $1937/oz Gold, $25/oz Silver, $1.78/lb Zinc, and $1.02/lb Pb. Assumed metal recoveries (rec.), based on a preliminary review of historic data by SRK and ProcessIQ², were 90% for each of copper, zinc, and lead, and 60% for each of gold and silver. The following equation was used to calculate copper equivalence: CuEq = Copper (%) (90% rec.) + (Gold (g/t) x 0.61)(60% rec.) + (Silver (g/t) x 0.0079)(60% rec.) + (Zinc (%) x 0.3844)(90% rec.) +(Lead (%) x 0.2203)(90% rec.). The following equation was used to calculate gold equivalence: AuEq = Gold (g/t)(60% rec.) + (Copper (%) x 1.638)(90% rec.) + (Silver (g/t) x 0.01291)(60% rec.) + (Zinc (%) x 0.6299)(90% rec.) +(Lead (%) x 0.3609)(90% rec.). Analyzed Metal Equivalent calculations are reported for illustrative purposes only. The metal chosen for reporting on an equivalent basis is the one that contributes the most dollar value after accounting for assumed recoveries.

Table 2 Continued. Full results of Phase 2 Drill Program at Kay Mine, Yavapai County, Arizona. The true width of mineralization is estimated to be 50% to 99% of reported core width, with an average of 80%.
