GT Gold Confirms Continuity of Higher-Grade Cu-Au Porphyry Mineralization to Depth of 1.2 Kilometres at Saddle North

VANCOUVER, British Columbia, Sept. 04, 2019 (GLOBE NEWSWIRE) -- GT Gold (TSX-V:GTT) (the “Company” or “GT Gold”) is pleased to announce results from the next eleven drill holes (TTD117 through 126) of its 10,000-metre Phase 1 exploration program at the Saddle North Cu-Au porphyry discovery within its 100%-owned Tatogga Project, in northwest B.C. Results support the expansion of the known higher-grade mineralization by approximately 100 metres along strike to the southeast at depth, and by approximately 200 metres along strike to the northwest near surface. In addition, the latest results confirm the continuity of excellent and increasing grades between the near-surface mineralization through moderate depths to the deeper and generally highest grade mineralization, where the system remains open.

The south-southwesterly-plunging, northerly-elongate higher-grade core zone now has approximate dimensions of 1,400-1,500 metres (down-plunge), 250-300 metres (thickness), and 400 metres (strike). It is contained within a well-mineralized northerly-trending and west-southwesterly dipping envelope 600 or 700 metres thickness, over 1,500 metres down-dip, and over 700 metres along strike. The system remains open in most directions, with highly prospective targets remaining at depth, to the west, and to the southeast.

Highlights:

Prices used to calculate CuEq and AuEq are: Cu: $2.57/lb, Au: $1,294.80/oz, Ag: $15.65/oz. All values are reported in USD and do not consider metal recoveries

  • TTD126: 0.57 g/t Au, 0.26% Cu, 0.96 g/t Ag (0.94 g/t AuEq) over 1,206 metres from 18 to 1,224 metres
    • Including 4.05 g/t Au, 0.30% Cu, 3.06 g/t Ag (4.49 g/t AuEq) over 51 metres from 410 to 461 metres (anomalously high gold values require follow up drilling to better understand their geometry, genesis and economic potential)
    • And including 0.94 g/t Au, 0.51% Cu, 1.74 g/t Ag (1.21% CuEq; 1.65 g/t AuEq) over 324 metres from 872 to 1,196 metres
    • Successfully extended the deep, high-grade mineralization intersected in 2018 drill holes (along strike from TTD109, down-dip from TTD093, see figs. 2 and 3)
  • TTD121: 0.43 g/t Au, 0.22 % Cu, 0.73 g/t Ag (0.54 % CuEq; 0.74 g/t AuEq) over 964 metres from 34 to 998 metres
    • Including 0.97 g/t Au, 0.42% Cu, 1.46 g/t Ag (1.56 g/t AuEq) over 230 metres from 734.5 to 964.3 metres
    • Shows that the excellent grades encountered in 2018 in drill hole TTD093 continue along strike approximately 100m to the southeast
  • TTD125: 0.37 g/t Au, 0.31% Cu, 1.00 g/t Ag (0.59% CuEq; 0.81 g/t AuEq) over 396.5 metres from 7.5 to 404 metres
    • Including 0.42 g/t Au, 0.39% Cu, 1.15 g/t Ag (0.71% CuEq; 0.96 g/t AuEq) over 257 metres from 136 to 393 metres
    • Demonstrates along-strike continuity to the northwest of near-surface Cu-Au mineralization encountered in drill holes TTD108 and 111

Most significantly, the deeper holes reported in this news release (TTD126, 121) extend the strike of Saddle North high-grade mineralization approximately 100 metres to the southeast, at depths equivalent to the deepest holes drilled in 2018 (TTD093, 109). Where the mineralization in all the holes is best developed, the step-outs occur across approximately 300 to 500 metres of down-dip extent. When considered in light of the results from the first six holes released in 2019, the new results suggest that the core zone intersected in TTD093 and 109, and linked to surface by higher grade intersections in drill holes such as TTD112, 108, 113 and 111, comprises a truly significant volume of higher-grade southerly-plunging core zone material at Saddle North.

Near-surface Saddle North drill holes in this news release at (TTD117-120, 123-125) returned grades in line with previous shallow drilling over lengths exceeding 250 metres. The continuity and consistency of grades in these holes confirm that near-surface bulk-tonnage Cu-Au porphyry potential exists at Saddle North, and it extends the strike-length of the mineralized zone beyond 700 metres, from TTD107 on the southeast, to TTD123 on the northwest.

“It is great to see such a robust set of results supporting continuity borehole to borehole and section to section,” commented Paul Harbidge, President and CEO.  “It is very encouraging to see increasing grade at depth.”

2019 Exploration Summary

The 10,000 metre Phase 1 drill program is now complete, with 8,652 metres reported. The program achieved positive results with respect to every objective – testing, confirming and extending continuity along strike, and from surface to depth.

Phase 2 drilling for is now underway. It will consist of approximately 15,000 metres for a total of 25,000 metres drilling in 2019. The exploration season is expected to last into late October, with infill drilling and expansion of Saddle North continuing to be the focus, but with possible testing of targets peripheral to Saddle North if time permits. Drill results will be released periodically throughout the season and likely into early 2020, as assays and other data are received and compiled.

GT Gold is also beginning consultation with engineering firms and others to develop a scope, schedule and budget for study work that will progress Saddle North through resource estimation and economic evaluation.

Table 1 – Saddle North Hole, Assay Results for Holes TTD117-127.  For hole locations, dips and azimuths, please refer to the accompanying drilling plan view (Figure 1) and drill sections (Figures 2 and 3), as well as Table 2, below. Widths reported are drilled core lengths. True widths are estimated at approximately 85% of drilled lengths.

Hole TTD117 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 36.50 479.00 442.50 0.22 0.49 0.20 0.37 0.50
Including 198.37 479.00 280.63 0.27 0.59 0.24 0.45 0.61
Including 254.00 479.00 225.00 0.29 0.59 0.25 0.47 0.64
Including 300.00 479.00 179.00 0.31 0.59 0.26 0.49 0.67
Including 416.00 479.00 63.00 0.50 0.91 0.37 0.74 1.01
Including 439.90 479.00 39.10 0.62 1.10 0.44 0.91 1.24



Hole TTD118 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 9.00 332.08 323.08 0.23 0.73 0.21 0.39 0.53
Including 99.00 332.08 233.08 0.28 0.87 0.25 0.46 0.63
Including 135.85 332.08 196.23 0.29 0.90 0.26 0.48 0.65
Including 135.85 248.49 112.64 0.36 1.11 0.30 0.57 0.78
Including 135.85 236.22 100.37 0.37 1.19 0.31 0.59 0.81
And Including 318.00 332.08 14.08 0.39 0.78 0.31 0.60 0.81



Hole TTD119 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 9.00 250.90 241.90 0.13 1.13 0.28 0.39 0.53
Including 65.00 250.90 185.90 0.14 1.26 0.31 0.42 0.58
Including 121.00 250.90 129.90 0.15 1.38 0.32 0.44 0.60
Including 165.00 250.90 85.90 0.16 1.73 0.36 0.49 0.67



Hole TTD120 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 5.48 342.00 336.52 0.21 0.82 0.29 0.45 0.61
Including 80.00 342.00 262.00 0.20 0.90 0.33 0.48 0.65
Including 80.00 120.00 40.00 0.33 1.17 0.38 0.63 0.86
Also including 248.00 340.00 92.00 0.30 1.19 0.50 0.73 1.00
Including 262.00 340.00 78.00 0.34 1.28 0.54 0.80 1.09
Including 284.00 340.00 56.00 0.41 1.36 0.58 0.89 1.21



Hole TTD121 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 34.00 998.14 964.14 0.43 0.73 0.22 0.54 0.74
Including 34.00 635.00 601.00 0.26 0.54 0.18 0.37 0.51
Including 145.00 635.00 490.00 0.29 0.61 0.20 0.42 0.58
Including 265.29 623.00 357.71 0.37 0.73 0.23 0.51 0.69
Including 265.29 552.00 286.71 0.40 0.86 0.27 0.57 0.77
Including 321.00 548.00 227.00 0.46 0.91 0.30 0.64 0.87
Including 321.00 463.00 142.00 0.49 1.05 0.32 0.68 0.93
Including 321.00 399.00 78.00 0.52 1.11 0.31 0.70 0.95
Also Including 734.50 964.29 229.79 0.97 1.46 0.42 1.14 1.56
Including 771.80 920.00 148.20 1.00 1.48 0.43 1.18 1.61



Hole TTD122 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 32.00 266.00 234.00 0.33 0.78 0.23 0.48 0.65
Interval 373.75 600.00 226.25 0.25 0.45 0.21 0.39 0.54
Including 373.75 403.68 29.93 0.25 0.56 0.24 0.43 0.58
Also including 471.00 600.00 129.00 0.30 0.49 0.24 0.47 0.64



Hole TTD123 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 83.00 113.00 30.00 0.14 0.49 0.11 0.20 0.30
Interval 197.00 351.12 154.12 0.08 0.82 0.20 0.27 0.37
Including 209.00 283.00 74.00 0.08 0.94 0.24 0.31 0.42
Also including 348.00 351.12 3.12 0.44 2.14 0.59 0.94 1.27



Hole TTD124 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 17.00 271.23 254.23 0.11 0.74 0.29 0.38 0.52
Including 77.42 271.23 193.81 0.13 0.83 0.35 0.46 0.62
Including 118.00 271.23 153.23 0.15 0.85 0.38 0.50 0.68
Including 148.00 166.00 18.00 0.17 1.40 0.57 0.71 0.97
And including 222.00 252.00 30.00 0.35 0.96 0.58 0.85 1.16



Hole TTD125 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 7.50 404.00 396.50 0.37 1.00 0.31 0.59 0.81
Including 34.00 404.00 370.00 0.39 1.04 0.33 0.62 0.85
Including 136.00 404.00 268.00 0.40 1.12 0.38 0.69 0.94
Including 136.00 393.00 257.00 0.42 1.15 0.39 0.71 0.96
Including 209.00 393.00 184.00 0.45 1.30 0.44 0.78 1.07
Including 287.55 337.00 49.45 0.57 1.43 0.53 0.97 1.32



Hole TTD126 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 18.00 1,224.00 1,206.00 0.57 0.96 0.26 0.69 0.94
Including 232.95 1,196.00 963.05 0.68 1.14 0.31 0.83 1.12
Including 410.00 1,196.00 786.00 0.81 1.29 0.35 0.96 1.30
Including 410.00 461.00 51.00 4.05 3.06 0.30 3.30 4.49
And Including 844.00 1,196.00 352.00 0.91 1.75 0.49 1.17 1.60
Including 872.00 1,196.00 324.00 0.94 1.74 0.51 1.21 1.65
Including 872.00 1,013.31 141.31 1.35 2.41 0.59 1.61 2.18



Hole TTD127 From  (m) To
(m)
Interval  (m) Au
(g/t)
Ag
(g/t)
Cu (%) CuEq* (%) AuEq*
(g/t)
Interval 187.00 773.26 586.26 0.20 0.46 0.21 0.36 0.50
Including 442.00 678.00 236.00 0.28 0.69 0.30 0.51 0.70
Including 610.00 678.00 68.00 0.49 1.16 0.47 0.85 1.15
And including 734.81 773.26 38.45 0.41 0.57 0.31 0.62 0.85


Table 2 – Saddle North Collar Information:
Refer to the accompanying drilling plan view and drill sections.

Hole Number Azimuth* (degrees) Dip* (degrees) Length (m) Elevation (m) UTM E UTM N
TTD117 42.7 -44.4   501 1,624 435985 6408331
TTD118 60.9 -44.3   351 1,636 436127 6408408
TTD119 59.4 -44.1   273 1,668 436075 6408610
TTD120 49.7 -45.0   402 1,652 435881 6408633
TTD121 33.7 -60.9   998 1,637 435806 6408049
TTD122 49.7 -76.8   644 1,652 435881 6408633
TTD123 49.3 -45.4   381 1,646 435808 6408708
TTD124 58.0 -45.2   282 1,678 435960 6408695
TTD125 47.5 -45.5   408 1,635 435902 6408537
TTD126 33.8 -77.8 1,224 1,637 435806 6408049
TTD127 34.7 -50.4   792 1,633 435746 6408207

*Hole orientation reported is the 0 meter collar shot taken using a REFLEX EZ-GYRO north seeking gyroscopic survey instrument.

Tatogga Property

GT Gold’s Tatogga Project lies in the northern part of northwest B.C.’s prolific Golden Triangle. The property features district scale exploration potential, with two recent discoveries, Saddle North and Saddle South, along with a third target, Quash-Pass, which is close to being drill-ready. All are proximal to Highway 37 and to grid power that leads to the nearby Red Chris copper-gold mine, approximately 20 km to the southeast. GT Gold is well funded, with a current cash position of approximately C$17.8 million.

Saddle North

Initial drilling at Saddle North followed indications from early rock and soil geochemical sampling, geology, and geophysical work which outlined a kilometre-scale geochemical, magnetic and Induced Polarization (IP) chargeability anomaly coincident with local exposure of quartz-sericite-pyrite altered rocks. Reconnaissance holes TTD062 and 064, completed late in the 2017 drilling season, indicated the presence of a copper-gold porphyry system that bore some similarities to the nearby Red Chris copper-gold mine. The results from the 2018 program demonstrated the potential for a significant copper-gold porphyry system at Saddle North, with grades exceeding 1.0% CuEq1 and 1.5 g/t AuEq1 in a higher-grade core zone (see news January 9, 2019). It also showed that this core zone reached from near surface (hole TTD108) to greater than 1,300 metres down-dip, where it remains open. True thickness of the core zone is approximately 100 metres in hole TTD108, at a depth of 200m. Copper equivalent grade appears to increase somewhat with depth, and in mineralized thickness increases to greater than 300 metres in holes TTD093 and TTD109. The 2018 results also demonstrated that the high-grade core zone extends along strike at least 500 metres (to hole TTD102) and that it lies within a much broader, strongly mineralized envelope with a drilled strike length in excess of 650 metres, a true thickness of approximately 700 metres, and a down-dip extent of more than 1,300 metres. The 2019 drilling suggests that the high-grade core zone also extends to surface to the northwest along trend of TTD108. This large, high-grade copper-gold mineralized zone generally appears to trend northwest-southeast or north-northwest to south-southeast and to dip steeply to the west-southwest or southwest, while the central higher-grade core zone may plunge similarly, to west-southwest or south-southwest.

Saddle South

The 2017 exploration program, testing a gold-in-soil anomaly with the first-ever drilling in the Saddle area, resulted in the discovery of the epithermal gold system at Saddle South. It is hosted by hydrothermally altered volcanic fragmental and volcaniclastic rocks of the Upper Triassic Stuhini Group that are cut by dikes primarily of latest Triassic and Early Jurassic age. Drilling defined a well-mineralized east-west trend of gold bearing sulphide-rich veins spanning roughly 400 metres along strike that is up to 150 metres across and is coincident with a moderate IP chargeability high and resistivity low. The 2017 drilling returned many high-grade intercepts (e.g., 51.53 g/t over 6.95 metres in TTD007; 20.02 g/t Au over 8.25 metres in TTD046), and the aim of the 2018 program at Saddle South was to further test the system along strike and to depth.

Drilling in the 2018 season at Saddle South expanded both the depth extent and the strike length of the mineralizing system. Deep intercepts on the west (e.g., TTD079), and on the east (e.g., TTD069), increased the size of the mineralized zone and expanded the exploration footprint. On the west margin of Saddle Ridge, and in all holes drilled west of the ridge and beneath the rock glacier in that direction, mineralized veins generally trend north-northeast (average strike 200) and dip moderately west-northwest (average 55°). Veins oriented in this direction correspond with a more southerly trend of the system, toward an area across the rock glacier where 2018 soil and talus fines sampling yielded highly encouraging results for gold (see news, September 4, 2018; figure 6). Also encouraging was the fact that drill holes collared from the rock glacier encountered less overburden than was expected (typically less than 30 metres), suggesting that the potential to the southwest may be readily tested.

QA/QC Procedures

GT Gold has implemented a rigorous quality assurance / quality control (QA/QC) program to ensure best practices in sampling and analysis of diamond drill core, the details of which can be viewed on the Company's website at http://www.gtgoldcorp.ca/projects/tatogga/. All assays are performed by ALS Canada Ltd., with sample preparation carried out at the ALS facility in Terrace, BC, and assays at the North Vancouver laboratory. Assay values are uncut. For gold, fire assays are performed as per ALS method Au-AA26 (0.01- 100.00 g/t Au) using 50 grams of sample measured by atomic absorption (AA). Assays equal to or greater than 100 g/t Au are reanalyzed gravimetrically by method Au-GRA22. Silver and copper are analyzed by ALS method ME-MS61 with a 4-acid digestion followed by ICP-MS analysis. Assays greater than 100ppm silver or 1% copper are reanalyzed by ICP-AES by method OG-62.

Qualified Person

Charles J. Greig, M.Sc., P.Geo., Vice President, Exploration for GT Gold Corp. and a Qualified Person as defined by NI 43-101, has reviewed and approved the technical information in this press release.

About GT Gold

GT Gold Corp. is focused on exploring for base and precious metals in the geologically fertile terrain of British Columbia’s renowned Golden Triangle. The Company’s flagship asset is the wholly-owned, 46,827 hectare Tatogga property, located near Iskut, BC, upon which it achieved two significant discoveries in 2017 and 2018 at its Saddle prospect: a near surface bulk-tonnage and potential deep high-grade underground-style epithermal gold-silver vein system at Saddle South and, close by at Saddle North, a large-scale, richly mineralized porphyry gold-copper-silver intrusion.

For further information, please contact:

GT Gold Corp.
Paul Harbidge
President and Chief Executive Officer
Tel: (647) 256-6752
Website: www.gtgoldcorp.ca
GT Gold Corp.
Charles J. Greig, P.Geo
Vice President, Exploration
Tel: (250) 492-2331
GT Gold Corp.
Amandip Singh
Director, Corporate Development
Tel: (647) 256-6754

Cautionary Statement Regarding Forward Looking Statements

This news release contains forward-looking statements and forward-looking information (together, "forward-looking statements") within the meaning of applicable securities laws. All statements, other than statements of historical facts, are forward-looking statements. Generally, forward-looking statements can be identified by the use of terminology such as "plans", "expects', "estimates", "intends", "anticipates", "believes" or variations of such words, or statements that certain actions, events or results "may", "could", "would", "might", "will be taken", "occur" or "be achieved". Forward looking statements involve risks, uncertainties and other factors disclosed under the heading “Risk Factors” and elsewhere in the Company’s filings with Canadian securities regulators, that could cause actual results, performance, prospects and opportunities to differ materially from those expressed or implied by such forward-looking statements. Although the Company believes that the assumptions and factors used in preparing these forward-looking statements are reasonable based upon the information currently available to management as of the date hereof, actual results and developments may differ materially from those contemplated by these statements. Readers are therefore cautioned not to place undue reliance on these statements, which only apply as of the date of this news release, and no assurance can be given that such events will occur in the disclosed times frames or at all. Except where required by applicable law, the Company disclaims any intention or obligation to update or revise any forward-looking statement, whether as a result of new information, future events or otherwise. Neither the TSX Venture Exchange nor its Regulation Services Provider (as that term is defined in the policies of the TSX Venture Exchange) accepts responsibility for the adequacy or accuracy of this release.

Figure 1

Figure 2

Figure 3
